Functional advantages:
Six independently adjustable three-phase signal sources to meet various on-site simulation environments required by the test terminal.
Support multiple forms of communication: including RS232, GPRS, CDMA, 230 radio, Ethernet, etc.
Reliable multi-channel pulse detection and accurate error processing technology can perform error test on common transformer and special transformer terminal.
SPWM technology Power amplifier, large capacity, high performance, low power consumption, automatic alarm protection.
Modular design, good component versatility, easy to disassemble and maintain.
One-key verification control management system, automatically completed according to the plan.
Standardized cabinet, one-time stamping and forming, all aluminum alloy frame, more beautiful and firmer.
In-depth customization according to functional requirements, more humanized and differentiated design.
