Main functions
Test energy meter under different current load with external supply power or internal voltage & current source;
Test current harmonic influence or other influence;
Display vectorgraph ,harmonic analysis and waveform, analyze the condition of state grid output;
Test voltage, current: directly or through current clamps;
Measure active, reactive and apparent power;
Measure phase angle, PF and frequency.
